MER2-630-18GC

The MERCURY2 GigE series (MER2-G) camera is DAHENG IMAGING's new generation industrial digital camera. With improved built-in ISP algorithms, MER2-G series camera supports more features. Providing multiple acquisition controls, the camera can adapt to various vision applications. The MER2-630-18GC camera is a color GigE Vision camera with the Sony IMX178 CMOS sensor. Thanks to the extremely compact, robust metal housings and locking screw connectors, the MERCURY2 cameras can secure the reliability of cameras deployed in harsh environments. The MER2-630-18GC camera has opto-isolated I/Os. The GPIOs give MER2-G cameras maximum flexibility to adapt to specific needs.


Features
  • Programmable ROI, increased frame rate with partial scan

  • Gain, exposure and white balance programmable

  • Support auto gain, auto exposure and auto white balance

  • Four acquisition controls: Single frame acquisition / Continuous acquisition / Software trigger acquisition / External trigger acquisition

  • Trigger mode: Frame Start /Frame Burst Start

  • Support Decimation, Binning, Reverse X/Y, Digital Shift and Black Level

  • Adjustable Gamma and Sharpness for optimizing the brightness and sharpness of images

  • Support Global Reset Release Shutter exposure

  • Support Light source preset, Color Transformation Control and Saturation

  • Programmable LUTs and storable user sets

  • Support Timer and Counter

  • Support Remove Parameter Limit to expand the range of exposure, gain, white balance, and so on

  • Adjustable packet-size and packet-delay, and reserved bandwidth

  • 16KB data storage area for saving algorithm coefficients and parameter configuration

  • Compatible with GenICam™ and GigE Vision®, can be used in a wide range of 3rd-party software such as HALCON, MERLIC and LabVIEW directly

  • Optimized software package for 32/64bit Windows, and support Linux, ARMv7, ARMv8 and Mac OS

  • Multiple samples and easy-to-integrate SDKs for various programming tools

Specifications
Model MER2-630-18GC
Product Families MERCURY2
Resolution 3088×2064
Frame Rate (fps) 18.45
Sensor Manufacturer Sony
Sensor 1/1.8" IMX178 Rolling shutter CMOS
Pixel Size 2.4μm
Pixel Bit Depth 8 bit,12 bit
Data Interface GigE
Lens Mount C,CS
Spectrum Color
Pixel Formats Bayer RG8,Bayer RG12
Signal Noise Ratio 39.65 dB
Power Requirement 12 ~ 24 VDC
Power Consumption < 3 W @ 24 VDC
Operating Temp. 0°C ~ +45°C
Storage Temp. -20°C ~ +70°C
Operating Humidity 10% ~ 80%
Dimensions (W×H×L) 29 mm × 29 mm × 29 mm (w/o connectors)
Weight 65 g
Conformity CE,FCC,RoHS,GigE Vision,GenICam
Spectral Response
