VEN-161-61U3C

The VEN-161-61U3C camera is a color all-in-one board level camera with the Sony IMX296 CMOS sensor. The VEN-161-61U3C provides four lens mount options: C mount with housing, S mount with housing, CS mount with housing and No mount (bare board). Thanks to the extremely compact housing and various mount options, the VEN-161-61U3C is more flexible in demanding space.

Features

USB3.0（Micro B）interface with 10-bit or 8-bit Bayer output
Gain, auto gain, exposure and auto exposure
Supports white balance, auto white balance and light source preset function
Storable user sets

Support Reverse X/Y (horizontal and vertical mirroring)
Support hardware trigger and software trigger
16KB data storage area for saving algorithm coefficients, parameter configuration, and so on

Specifications

Model	VEN-161-61U3C
Product Families	VENUS
Resolution	1440×1080
Frame Rate (fps)	61.2
Sensor Manufacturer	Sony
Sensor	1/2.9" IMX296 Global shutter CMOS
Pixel Size	3.45μm
Pixel Bit Depth	8 bit，10 bit
Data Interface	USB3.0
Lens Mount	No-mount，C，S，CS
Spectrum	Color
Pixel Formats	Bayer RG8，Bayer RG10
Signal Noise Ratio	40.6 dB
Exposure Time	20μs ~ 1s
Gain	0dB ~ 24dB
Reverse X/Y	Reverse X/Y
I/O Interface	1 input with opto-isolated, 1 programmable GPIO
Power Requirement	Power over USB3.0
Power Consumption	1.21 W @ 5 VDC
Operating Temp.	0°C ~ +45°C
Storage Temp.	-20°C ~ +70°C
Operating Humidity	10% ~ 80%
Weight	No-mount: 7 g
Conformity	CE, RoHS, USB3 Vision, GenICam
