MARS-24600-12X2M-TF

MARS-24600-12X2M-TF camera is equipped with Sony IMX811 245.76MP rolling shutter sensor and uses CoaXPress interface for high-speed transmission of image data, featuring high quality images, low power consumption, high transmission speed, stable operating capability.

Features

PRNU, DSNU, FFC, Static Defect Correction
The Sequencer Control supports parameter configuration of exposure, gain, and FFC up to 16 groups

Gamma, Binning, Timer, Counter, LUTs and User Set Control
DAHENG IMAGING or third-party frame grabbers are available

Specifications

Model	MARS-24600-12X2M-TF
Product Families	MARS
Resolution	19200×12800
Frame Rate (fps)	10.54
Sensor Manufacturer	Sony
Sensor	64.84mm IMX811 245.76MP Rolling shutter CMOS
Pixel Size	2.81μm
Pixel Bit Depth	8 bit，12 bit，14 bit，16 bit
Data Interface	CoaXPress
Lens Mount	M72
Spectrum	Mono
Pixel Formats	Mono8，Mono12，Mono14，Mono16
Signal Noise Ratio	44.2 dB
Exposure Time	Bayer RG8: 144μs ~ 60s. Bayer RG12: 123μs ~ 60s. Bayer RG14: 144μs ~ 60s. Bayer RG16: 287μs ~ 60s
Gain	Digital Gain: 0dB~24dB, Analog Gain: 0dB~16dB
Binning	-
Decimation	1×1, 1×2, 1×4, 2×1, 2×2, 2×4, 4×1, 4×2, 4×4
Reverse X/Y	Reverse X/Y
I/O Interface	1 input and 1 output with opto-isolated, 1 bidirectional GPIO, 1 RS232
Power Requirement	24 VDC or PoCXP
Power Consumption	Typical: 40.6W@24V, ambient temp. 25°C, Sensor temp. 10°C, TEC (ON), FAN (ON). 44W@Rapid cooling stage, TEC (ON), FAN (ON)
Operating Temp.	0°C ~ +45°C
Storage Temp.	-20°C ~ +70°C
Operating Humidity	10% ~ 80%
Dimensions (W×H×L)	120mm × 120mm × 118mm (M58), 74mm × 74mm × 112.9mm (F)
Weight	2340 g
Conformity	CE, RoHS, FCC, ICES, UKCA, CoaXPress2.0, GenICam
