MER3-800-86X2M

The MER3-800-86X2M camera is equipped with global shutter sensor and uses CoaXPress2.0 interface for high-speed transmission of image data, featuring high quality images, extremely low power, small housing, and stable operating capability. The camera is capable of 12.5Gbit/s maximum transfer data rate, support PoCXP and can secure the reliability of cameras deployed in harsh industrial environments. The cameras are industrial cameras with high reliability, high transmission speed and high image quality.

Features

The Sequencer Control supports multiple sets of parameters configuration
Black Level, Timer, Counter, LUTs and User Set Control

Brightness, Contrast, Gamma, LUTs, User Set Control
DAHENG IMAGING or third-party frame grabbers are available

Specifications

Model	MER3-800-86X2M
Product Families	MERCURY3
Resolution	2840×2840
Frame Rate (fps)	86.76
Sensor Manufacturer	Sony
Sensor	2/3" IMX546 Global shutter CMOS
Pixel Size	2.74μm
Pixel Bit Depth	8 bit, 10 bit, 12 bit
Data Interface	CoaXPress
Lens Mount	C
Spectrum	Mono
Pixel Formats	Mono8, Mono10, Mono12
Signal Noise Ratio	Mono8: 39.663 dB, Mono10: 39.58 dB, Mono12: 39.917 dB
Exposure Time	UltraShort: 1μs ~ 2.4μs, Standard: 3μs ~ 1s
Gain	AnalogALL: 0dB~24dB
Binning	Sensor: 1×1, 2×2
Decimation	Sensor: 1×1, 2×2
Reverse X/Y	Reverse X/Y
I/O Interface	1 input with opto-isolated, 2 programmable GPIOs
Power Requirement	Power over CoaXPress
Power Consumption	3.164 W @ PoCXP
Operating Temp.	0°C ~ +45°C
Storage Temp.	-20°C ~ +70°C
Operating Humidity	10% ~ 80%
Dimensions (W×H×L)	29 mm × 29 mm × 34 mm
Weight	60 g
Conformity	CE, RoHS, FCC, ICES, UKCA, CoaXPress2.0, GenICam
